Boss IR-200 Amp and IR Cabinet Pedal-Based Amp Simulator

Boss IR-200 Amp and IR Cabinet Pedal-Based Amp Simulator

Direct Amp and IR Power for Performance, Recording, and Practice
Introducing the IR-200, the most advanced compact amp/IR solution available. This powerhouse stomp brings next-level performance to direct sound for guitar and bass, offering exceptional audio quality, premium amps, deep sound shaping, and instant sound recall with 128 memories. Over 150 hi-res cab impulse responses from BOSS and Celestion Digital are on board, plus 128 locations for loading your own mono or stereo IRs.

Description

The IR-200 turns your pedalboard into a self-contained direct sound solution for live playing, studio recording, and practice. It delivers massive amp tones from a small footprint and smoothly integrates with all your favorite pedals, including stereo mod, delay, and reverb effects. And once you craft your tones, you can send them to a stage amp, house PA, computer recording system, or headphones—or all at once.

Features

• Pedal-based amp simulator and impulse response loader with premium sound and features
• 32-bit AD/DA, 32-bit floating-point processing, and 96 kHz sampling rate
• 128 user IR slots with support for mono and stereo WAV files, up to 32-bit floating point/96 kHz resolution, and 200 or 500 ms length
• Large onboard preset cab IR library with 144 BOSS IRs and 10 Celestion Digital IRs
• Class-leading IR reproduction with two custom DSPs
• Eight guitar and three bass amp types to cover a wide range of styles
• Run up to two IRs at once in mono or stereo
• 128 memories for storing user setups
• Two EQs in each memory plus two global EQs, all with selectable parametric or graphic operation
• Room, Studio, and Hall ambience types
• Effects loop with mono send and mono/stereo return, with selectable pre-cab or post-EQ positioning
• Dedicated software for loading cab IRs and backing up memories
• Versatile USB audio interface for recording and playback with music software on Mac and Windows computers and iOS devices
• Deep external control support via footswitches, an expression pedal, and TRS MIDI

Specs

Sampling frequency:  96 kHz

AD Conversion:  32 bits + AF method
* AF method (Adaptive Focus method) is a proprietary method from Roland & BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA converters.

DA Conversion:  32 bits

Processing:  32-bit floating point

Memory:  128

IR cabinet data format:  Mono/stereo, Maximum 500 ms, 44.1/48/96 kHz, 16 bits linear/24 bits linear/32-bit floating point

Preset IR cabinet:  154

User IR cabinet slot:  128

Normal input level

INPUT, RETURN: -10 dBu
AUX IN: -20 dBu

Maximum input level:  INPUT, RETURN: +7dBu, AUX IN: 0 dBu

Input impedance:  INPUT, RETURN: 1 M ohm, AUX IN: 27 k ohms

Normal output level:  OUTPUT (A/MONO, B), SEND, PHONES: -10 dBu

Maximum output level:  OUTPUT (A/MONO, B), SEND, PHONES: +7dBu

Output impedance:  OUTPUT (A/MONO, B), SEND: 1k ohm

PHONES: 44 ohms

Recommended load impedance:  OUTPUT (A/MONO, B), SEND: 10 k ohms or greater

PHONES: 44 ohms or greater

Controls

DOWN switch, UP switch
MENU button, EXIT button
MEMORY knob, AMP knob, CABINET knob, AMBIENCE knob
GAIN knob, LEVEL knob, BASS knob, MIDDLE knob, TREBLE knob

Display:  Graphic LCD (132 x 32 dots, backlit LCD)

Connectors

INPUT, SEND, OUTPUT (A/MONO, B) jacks: 1/4-inch phone type
RETURN jack: 1/4-inch TRS phone type
AUX IN: Stereo miniature phone type
CTL 1, 2/EXP jack: 1/4-inch TRS phone type
MIDI (IN, OUT) connectors: Stereo miniature phone type
USB COMPUTER port: USB Micro-B type
DC IN jack

Power supply:  AC adaptor

Current draw:  335 mA

Accessories

AC adaptor
Owner's Manual
Leaflet "USING THE UNIT SAFELY"
Rubber foot x 4

Options (sold separately)

Footswitch: FS-5U
Dual footswitch: : FS-6, FS-7
Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
TRS/MIDI cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535

SIZE AND WEIGHT

• Width:  101 mm/4 inches
• Depth:  138 mm/5-7/16 inches
• Height:  63 mm/2-1/2 inches
• Height (including rubber feet):  65 mm/2-9/16 inches
• Weight (excluding AC adaptor):  660 g/1 lb 8 oz

* 0 dBu = 0.775 Vrms

*The specifications are subject to change without notice.
