Mackie MDB-2P Passive Direct Box


The Mackie MDB-2P is a stereo passive direct box designed to connect two mono instruments or a single stereo instrument to microphone preamps for musicians and audio engineers in recording sessions, houses of worship, and live stage applications.

Description

The MDB-2P converts high-impedance, instrument-level signal via its 1/4" TS unbalanced inputs to low-impedance, mic-level outputs via balanced XLR 3-pin jacks. Two 1/4" TS thru jacks allow simultaneous connection to amplifiers or pedalboards.

Each channel offers a -15 dB pad for reducing the input level to prevent distortion when using a high-gain source. The ground-lift switch inhibits hum caused by ground loops. Due to passive design principles, the MDB-2P requires no batteries or power supply. Its sturdy steel chassis enables confident use in the studio or on the road.


Features
  • Connect two mono instruments such as guitars or basses or a stereo instrument such as a keyboard to microphone preamps
  • Converts high-impedance, unbalanced 1/4" TS inputs to low-impedance, balanced XLR mic-level outputs
  • 1/4" thru jacks for routing to amplifiers or pedalboards
  • Per-channel -15 dB pad prevents overloading when accepting signal from a loud source
  • Ground-lift switch minimizes hum
  • Passive design requires no batteries or power supply

Specs

Audio Performance

  • Frequency Response:  20 Hz - 20 kHz, ±0.2dB
  • Dynamic Range:  128dB
  • Total Harmonic Distortion:  0.002% from 1000Hz
  • Pad: -15dB

Input/Output

  • Input Type:  Female 1/4" Unbalanced
  • Input Impedance: 140 kΩ unbalanced
  • Impedance Ratio (Input to Output): 350:1
  • Output Type:  Male XLR Balanced
  • 1/4" Unbalanced (Thru)
  • Output Impedance:  400Ωbalanced

Physical Properties

  • Height:  1.5in/38mm
  • Width:  3.4in/86mm
  • Depth:  5.8in/147mm
  • Weight:  0.8lb/0.4kg
